Maximus-3 Superwinch SX Winch Mount Package; Wrangler JL & Gladiator JT w/ Steel Bumper Group

This winch mount package includes everything you need to install the Superwinch SX winch of your choice in your Wrangler JL or Gladiator JT with factory steel bumper group. Below is the product information for the different winch choices, and the Maximus-3 winch mount.

The SX winch is designed to provide users with the perfect mixture of speed, power, innovation, and the tested performance they demand from Superwinch. Standard and innovative features include a relocatable die-cast aluminum control box, a patented drum light, 12ft lighted wired remote, and a 3/8" diameter steel wire rope, or synthetic rope. SX Series winches surpass the most demanding standards of any old or modern vehicles, while offering an affordable and stylish design and incorporating multiple class-leading features that can't be found in other high-performance winches. With a choice of 10,000 or 12,000 lbs. of raw pulling power, the new SX model has a clean modern look and is built to last the life of your vehicle. An IP68 rating offers piece of mind with waterproof and dustproof operation, and a durable metallic graphite powder-coated finish. This winch has it all!

SX10 & SX10SR Winch Features:

• 5.5 HP Sealed Motor
• Pull & Turn Clutch Handle
• 3/8" x 85' Steel Wire Rope or 3/8" x 80' Synthetic Rope
• 10,000 Pound Line Pull Rating
• 3-Stage Planetary Gearing w/ 218:1 Ratio
• IP68-Rated Dustproof & Waterproof Winch
• Rechargeable 12' Hand Held Wired Remote
• Aluminum Die-Cast Relocatable Control Box
• 100% Full Load Holding Automatic Mechanical Brake
• Integrated Lithium Ion Battery & Flashlight in Remote
• HD Clevis Winch Hook & Stainless Steel 4-Way Roller Fairlead or Aluminum Hawse Fairlead

SX12 & SX12SR Winch Features:

• 6 HP Sealed Motor
• Pull & Turn Clutch Handle
• 3/8" x 85' Steel Wire Rope or 3/8" x 80' Synthetic Rope
• 12,000 Pound Line Pull Rating
• 3-Stage Planetary Gearing w/ 231:1 Ratio
• IP68-Rated Dustproof & Waterproof Winch
• Rechargeable 12' Hand Held Wired Remote
• Aluminum Die-Cast Relocatable Control Box
• 100% Full Load Holding Automatic Mechanical Brake
• Integrated Lithium Ion Battery & Flashlight in Remote
• HD Clevis Winch Hook & Stainless Steel 4-Way Roller Fairlead or Aluminum Hawse Fairlead

Winch Mount Specifications:

• Winch Mount Includes Front Trim Plate
• Designed Specifically to Fit 2018 + Wrangler JL & Gladiator JT Steel Front Bumpers
• Made of a One Piece Heavy Gauge Bent Steel Plate - Process: laser cut, press brake, & welding
• Durable Black Textured Powder Coat Paint
• Mounts Directly to the Vehicle's Chassis Frame
• Made in The United States

This inboard chassis-secured winch mount will get you out of sticky situations. The plate is made of heavy gauge steel and is cleverly engineered to provide a structurally sound mount for your winch. This is the perfect mount and includes everything needed to install the Superwinch SX winch you choose.
